Lime

class sf3dmodels.rt.Lime(GRID)

Bases: sf3dmodels.rt.MakeDatatab

Base class for lime related objects. Contains base functions to write formatted files to perform Radiative Transfer calculations with LIME.

• Input and output units: SI (metres, kilograms, seconds).

Parameters:

GRID : Struct

Grid structure in which the model was computed.

Notes

Available grid [0,1,2,3] and physical properties for Lime, their id and description:

prop key	id	Description
id	0	cell id
x	1	x coordinate
y	2	y coordinate
z	3	z coordinate
dens_H2	4	Molecular Hydrogen density
dens_p_H2	5	ParaHydrogen density
dens_o_H2	6	OrthoHydrogen density
dens_e	7	Electronic density
dens_H	8	Atomic Hydrogen density
dens_He	9	Helium density
dens_Hplus	10	Ionized Hydrogen density
temp_gas	11	Gas temperature
temp_dust	12	Dust temperature
vel_x	13	Velocity along x-axis
vel_y	14	Velocity along y-axis
vel_z	15	Velocity along z-axis
abundance_0	16	Molecular abundance(s)
abundance_1
…
abundance_n
gtdratio	17	Gas-to-dust (mass) ratio
doppler	18	Doppler broadening via turbulence
	4242	End of file in header.dat

Methods Summary

finalmodel(self, prop[, fmt, folder])

Writes the final model into file.

Methods Documentation

finalmodel(self, prop, fmt='%.6e', folder='./')

Writes the final model into file. The output is ready to be read with LIME

Parameters:

prop : dict

Dictionary containing the model physical properties.

See the Notes section above for a list with the available input properties.

fmt : str or dict, optional

If str: Format string for all the columns. Defaults to ‘%.6e’.

If dict: the input keys of the dictionary must be present in the prop keys. The keys in prop which were not specified in the fmt dict, will be written with the default format ‘%.6e’.

folder : str, optional

Sets the folder to write the files in. Defaults to ‘./’.

Returns:

‘datatab.dat’ : file

Data file made from the prop’s content. The columns are sorted according to the id’s table in the Notes section of the Lime class.

‘npoints.dat’ : file

File containing the number of columns in ‘datatab.dat’, the number of cells along x,y,z, and the total number of cells.

‘header.dat’ : file

File specifying the column ids according to the table in the Notes section of the Lime class.

‘x.dat’ : file

‘y.dat’ : file

‘z.dat’ : file

Examples

Have a look at the following folders on the GitHub repository:

examples/single_main/

examples/hamburger_tapering/

examples/two_sources/

Attributes:

prop_header : dict

Dictionary relating the input prop keys to their characteristic id according to the Lime requirements.

prop_keys : array_like

Array object containing the column names of the physical properties written into file.

columns : array_like

Array object containing all the column names written into file. The prop columns are sorted based on their characteristic id from the Lime class.
